COLOURS
Dashwood vinyl windows come standard with white interiors and exteriors. Choose from the optional exterior colours shown.
Custom colours and interior finishing is also available.
Dashwood windows with optional colours feature a revolutionary coating specially formulated for vinyl that is designed and tested for superior performance in all environmental conditions to resist peeling, flaking and chalking.
Optional
Standard DI White
Sandstone
Sable
Terrastone
Dark Brown
Black
Additional
Cloud White
Royal White
Maize
Country Almond
Wicker
Sandalwood
Beige
Canyon Clay
Hickory
Storm
Charcoal
Bahama Brown
Bronze
Red Rock
Brick Red
Crimson Red
Cranberry
Forest Green
Old World Blue
GLASS
Dashwood windows feature insulating glass manufactured by Cardinal Glass Industries, a leader in the development and manufacture of advanced residential glass for windows and doors.
Choose the glass that best suits your situation and objectives.
Endur IG spacer
- Stainless steel spacer
- Desiccant material
- “Polyisobutylene” primary seal
- Specially formulated secondary seal
CARDINAL LOĒ-180™
- Best total performance for colder climates
- Blocks heat loss to the outside and reflects heat back into the room
- Allows the winter sun’s heat to pass into the room
- Standard in Dashwood windows
CARDINAL LOĒ²-272®
- Year round performance
- In winter reflects heat back into the room
- In summer reflects sun’s heat and damaging UV rays
CARDINAL LOĒ³-366®
- 3 layers of Low-E coating
- High solar control without a dark tint appearance
- Balanced performance for year-round comfort
CARDINAL LOĒ²-240®
- Perfect choice for high solar glare locations
- Blocks solar heat gain maintaining cooler indoor temperatures
- Tinted appearance reduces visible light by 60%
Textured Glass Options
Obscured
Rain
Hurricane
Glue Chip
Sandblast
GLASS PRESERVE™ PROTECTIVE FILM
A little added insurance for your new window investment. This optional removable protective film is applied to the exterior and interior glass surfaces at the factory to shield the glass from unwanted debris and scratches during shipping, handling and installation. Peels away when the job is finished to reveal clear unblemished glass.
NEAT® NATURALLY CLEAN GLASS
A special titanium-dioxide coating applied to the glass exterior reacts with the sun’s UV rays to loosen the bond of organic material to the glass surface. Dirt is easily rinsed away with rain. The extremely smooth surface of Neat Glass sheets water away promoting faster evaporation and reduced water spotting resulting in cleaner, clearer glass. Optional in Dashwood windows. Includes Preserve™ protective exterior film.
All Gemini® Series window come standard with double pane Low E Glass or Optional Triple Pane Glass
Triple Pane exterior view
Triple Pane interior view
Hardware
CASEMENTS & AWNINGS locking and operating hardware
Standard casement and awning locking and operating hardware comes with white or black finish. A folding crank handle is optional.
Optional Truth Encore®
Single and Double Hung hardware
Traditional Double-Hung style windows feature upper and lower sashes that slide up and down for ventilation. Both sashes tilt inward for easy cleaning.
- Cam-Action Lock and Keeper – work in conjuction with interlocking meeting rail, pocket sill design and weather sealing system for weather-tight security. Available white or black finish.
- Recessed Tilt Laches – finger activated latch release locks allow sash to swing inwards for cleaning; recessed for a clean interior appearance.
- Constant Force Coil Balance System – concealed within the frame, each coil balance is gauged for the specific sash size and weight; requires less effort to raise and lower the sash compared to other spiral balance systems.
Gliding hardware
Cam-Action Lock and Keeper – work in conjuction with interlocking meeting rail, pocket sill design and weather sealing system for weather-tight security. Available white or black finish.
GRILLES AND DIVIDED LITES
Dashwood windows are available with grille and divided lite options in a number of standard patterns and custom configurations.
Grille Patterns
Colonial
Prairie
Craftsman
Custom
Diamond
Renaissance
INTERNAL GRILLES BETWEEN THE GLASS (GBG)
Permanently sealed inside the insulating glass for traditional appearance and easy cleaning. Choose from flat or contoured profiles in widths shown.
SIMULATED DIVIDED LITES (SDL)
Grille bars are permanently applied to the interior and exterior glass surfaces to create the look of individual true divided lites while maintaining the energy efficiency of modern insulating glass. Add an optional spacer between the glass for an even more authentic appearance.
INTERIOR JAMB OPTIONS
Gemini Interior jamb extensions are available factory applied or loose to suit standard wall dimensions of 4-9/16”, 5-1/8”, 6-9/16” and 7”. Custom dimensions are also available. Choose from these material types.
EXTERIOR FRAME AND BRICKMOULD OPTIONS
A selection of exterior brickmould profiles are offered for use in conjunction with exterior masonry or siding applications.
An authentic sillnose is also offered for an architecturally correct appearance.
Exterior accessories may be colour coordinated to window exteriors or a different colour can be specified for a custom 2-tone appearance.
1''
1 ¼'' w/J Channel
1 ¼''
1 ½''
2''
2 ½'' w/J Channel
Sill Nosing w/ End Cap
Gemini Sizes
Gemini Series come in hundreds of convenient standard sizes for new build or custom sizes for those unique renovation needs.
Screens and Accessories
STANDARD SCREENS
Standard screens feature charcoal fibreglass 18 X 16 mesh in aluminum frame with exposed fasteners. An optional wide surround frame with concealed fasteners is available for casement and awning windows.
CLEARVIEW SCREENS
Optional Clearview screens feature fine gauge 20 X 20 fiberglass mesh for greater visual clarity. Clearview screens for casement and awning CAN come with OPTIONAL wide surround frame and concealed fasteners.
Screen frame colour is coordinated to the interior colour on casement and awning and to the exterior colour on hung and gliding windows.
Installation Accessories
Interior Installation Bracket
Exterior Installation Bracket
Installation Strap
